0. 前言

本身有台 Thinkpad X220，內裝有 Micron Crucial SSD 兩顆，分別是 Crucial M4 mSata SSD 128G (CT128M4SSD3) 以及 Crucial MX200 256G (CT250MX200SSD1)。前者在 2012 年購買，後者在 2015 年購買。

這次想要升級的原因，是因為在 windows 下發現作為系統碟的 M4 mSata 出現多磁區錯誤以及重新分配的狀況，查看其韌體後發現是最老的版本 (01MH)，目前網路上可以查到的版本為 07MH。為了 SSD 的健康，決定升級韌體。

在美光的網站下載相對應的韌體後，解壓縮開啟程式準備安裝。參照最新的 Guideline 後，可以得知目前 (2015後) 都會採用 bootable 的方式進行，因此不用再額外準備 USB 來製作開機碟。這是好事，但是一想到電腦上有 GRUB，就覺得有點問題。

果不其然，在安裝好韌體更新程式後，電腦自動重新開機，回到 GRUB2 的選單，選擇 windows 後轉入 repair mode。但是在這個環節出現無法開機 (not bootable) 的畫面，連續點選確認後，跳回 windows 7 運行選單，選擇後轉回正常 win7 開機畫面。

1. 找尋 Linux / GRUB 解決方案

在網路上翻找一番，在 guillaume 於 2016/2/28 發表的 Update any crucial ssd firmware from linux/grub 找到一份以 perl 寫成的 script，其作法非常簡潔。以 root 權限執行 script 後，會下載在 crucial-fw.cfg 設定相對應得 firmware zip file，解壓出裡面的 iso，放入 /boot 下同時產生 grub config file，使用者只要重新產生 grub.cfg，重新開機後就會看到相對應的選單。

原理是因為，這些 bootable iso 是以 syslinux 的 isolinux 與 memdisk 的格式包裝，因此只要在 GRUB 中做相對應的設定，就可以在開機的時候進入。作者在文章中有提到：

Since these isos are using isolinux … an unfair nonsense.
Why didn’t they add “and Linux and BSD and everything x86”? or simply put “for PC and Mac” (another possible nonsense since a Mac is a classic x86 hardware platform).

以下簡單分析 crucial-fw.pl 這個 script 在做什麼事情，使他可以做成 GRUB2 的 Crucial firmware update options.

## Crucial firmware 設定檔，以 name (tab) url 的方式儲存資料
my $LIST	= “./crucial-fw.cfg”;
## 下載下來的 zip file 會放置在 fw 中，並且解壓縮
my $DWN_DIR	= “./fw”;
## 臨時用來 mount firmware iso 的資料夾，用來檢測 iso 的 boot type
my $MNT_DIR 	= “./mnt”;
## GRUB2 設定檔的位置
my $GRUB_FILE	= “/etc/grub.d/45_crucial-fw”;
## 放置 bootable iso 的位置
my $ISO_DIR	= “/boot/crucial-fw”;

## Crucial firmware 設定檔，以 name (tab) url 的方式儲存資料

my $LIST = “./crucial-fw.cfg”;

## 下載下來的 zip file 會放置在 fw 中，並且解壓縮

my $DWN_DIR = “./fw”;

## 臨時用來 mount firmware iso 的資料夾，用來檢測 iso 的 boot type

my $MNT_DIR = “./mnt”;

## GRUB2 設定檔的位置

my $GRUB_FILE = “/etc/grub.d/45_crucial-fw”;

## 放置 bootable iso 的位置

my $ISO_DIR = “/boot/crucial-fw”;

可以看到，因為 script 會需要處理到需要 root 權限的東西 (mount, /boot/)，因此會要求在執行的時候以 root 權限執行。

重要的部分是在 script 製作 grub config file 以及檢測 iso boot type 的部分。整個 grub config file 的 template 是這樣的格式：

#!/bin/sh
exec tail -n +3 $0
submenu ‘Crucial Firmware Update’ {
    menuentry “$tg FW” {
        insmod loopback
        set isofile=”$ISO_DIR/tg.iso”
        search -sf $isofile
        loopback loop $isofile
        #     Is linux16 (memdisk)
        # linux16 (loop)/boot/isolinux/memdisk
        # initrd16 (loop)/boot/isolinux/boot2880.img
        #     Is initrd (isolinux), first parse append boot options
        # linux (loop)/boot/vmlinuz $append
        # linux (loop)/boot/core.gz
    }
}

#!/bin/sh

exec tail –n +3 $0

submenu ‘Crucial Firmware Update’ {

menuentry “$tg FW” {

insmod loopback

set isofile=“$ISO_DIR/tg.iso”

search –sf $isofile

loopback loop $isofile

# Is linux16 (memdisk)

# linux16 (loop)/boot/isolinux/memdisk

# initrd16 (loop)/boot/isolinux/boot2880.img

# Is initrd (isolinux), first parse append boot options

# linux (loop)/boot/vmlinuz $append

# linux (loop)/boot/core.gz

}

在每個 iso file 中，script 會將他 mount 到前面設定的 mnt 資料夾中，接著檢查該 iso 中是否有存在 memdisk / boot2880.img 或是 vmlinuz / core.gz 檔案。如果有存在 memdisk 的話，在 menuentry 中會輸出 linux16 的部分。如果有存在 vmlinuz 的話，會輸出 initrd 的部分。

整個 script 最核心的部分就是這邊，透過這樣的方式便能夠輸出一份 GRUB config file，使用者只要在透過 update-gurb2 或 gurb-mkconfig 就能夠輸出含有 Crucial Firmware Update 的 GRUB.cfg。

3. 轉換為 Python (>3.3)

看不太懂 Perl，因此把整個 script 轉換為 Python，除了提升可讀性外，另一個好處是都使用 Python-builtin 的套件，不用像 Perl 需要額外安裝其他套件。

完整的 source code 放置於 GitHub: crucial-ssd-firmware-grub

原本 guillaume 的 code 是宣告為 public domain，在這邊也是以 unlicense 的方式發佈。

#! /usr/bin/env python3
# -*- coding: utf-8 -*-
#
# 2017 Louie Lu <me at louie.lu>
#
# This is free and unencumbered software released into the public domain.
#
# Anyone is free to copy, modify, publish, use, compile, sell, or
# distribute this software, either in source code form or as a compiled
# binary, for any purpose, commercial or non-commercial, and by any
# means.
#
# In jurisdictions that recognize copyright laws, the author or authors
# of this software dedicate any and all copyright interest in the
# software to the public domain. We make this dedication for the benefit
# of the public at large and to the detriment of our heirs and
# successors. We intend this dedication to be an overt act of
# relinquishment in perpetuity of all present and future rights to this
# software under copyright law.
#
# THE SOFTWARE IS PROVIDED “AS IS”, WITHOUT WARRANTY OF ANY KIND,
# EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF
# MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT.
# IN NO EVENT SHALL THE AUTHORS BE LIABLE FOR ANY CLAIM, DAMAGES OR
# OTHER LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE,
# ARISING FROM, OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR
# OTHER DEALINGS IN THE SOFTWARE.
#
# For more information, please refer to <http://unlicense.org/>
#

import logging
import os
import shutil
import zipfile
import tempfile
import urllib3

CHUNK_SIZE = 2048
CONFIG_FILE = ‘crucial-fw.cfg’
GRUB_FILE = ‘/etc/grub.d/45_crucial_fw’
BOOT_ISO_DIR = ‘/boot/crucial-fw’
DOWNLOAD_DIR = tempfile.mkdtemp()


def read_config(path):
    f = open(path).readlines()
    f = filter(lambda x: not x.startswith(‘#’), f)
    f = filter(lambda x: not x.startswith(‘\n’), f)
    f = filter(lambda x: not x.startswith(‘\n\r’), f)
    f = list(map(lambda x: x.strip(‘\n\r’).split(‘\t’), f))

    return f


def open_custom_grub_config():
    f = open(GRUB_FILE, ‘w’)
    f.write(“#!/bin/sh\nexec tail -n +3 $0\nsubmenu ‘Crucial Firmware Update'{\n”)

    return f


def download_firmware_zip(name, url):
    logging.info(‘    [*] Downloading…’)
    http = urllib3.PoolManager()
    r = http.request(‘GET’, url, preload_content=False)

    path = ‘%s/%s.zip’ % (DOWNLOAD_DIR, name)
    with open(path, ‘wb’) as f:
        while True:
            data = r.read(CHUNK_SIZE)
            if not data:
                break
            f.write(data)
    r.release_conn()
    return path


def extract_zip_to_iso(path):
    logging.info(‘    [*] Uncompressing…’)
    z = zipfile.ZipFile(path, ‘r’)

    iso = z.namelist()[0]
    z.extractall(DOWNLOAD_DIR)
    z.close()

    return iso


def move_iso_to_boot(iso):
    logging.info(‘    [*] Moving iso to %s’ % (BOOT_ISO_DIR))
    if not os.path.isdir(BOOT_ISO_DIR):
        os.mkdir(BOOT_ISO_DIR)
    if os.path.isfile(‘%s/%s’ % (BOOT_ISO_DIR, iso)):
        os.remove(‘%s/%s’ % (BOOT_ISO_DIR, iso))

    shutil.move(‘%s/%s’ % (DOWNLOAD_DIR, iso), BOOT_ISO_DIR)


def parse_isolinux_config(path):
    with open(‘%s/boot/isolinux/isolinux.cfg’ % (path)) as f:
        for n in f.readlines():
            if n.startswith(‘APPEND’):
                return ‘ ‘.join(n.strip(‘\n’).split(‘ ‘)[1:])

    return ”


def make_grub_menuentry(fgb, name, iso):
    with tempfile.TemporaryDirectory() as mount_dir:
        logging.debug(‘Mount dir: ‘, mount_dir)
        logging.info(‘    Grub mode:’)
        os.system(‘mount -o loop %s/%s %s 2>/dev/null’ % (BOOT_ISO_DIR, iso, mount_dir))
        fgb.write(
            ”’menuentry “%s FW” {
            insmod loopback
            set isofile=”%s/%s”
            search -sf $isofile
            loopback loop $isofile
            ”’ % (name, BOOT_ISO_DIR, iso))

        if (os.path.isfile(‘%s/boot/isolinux/memdisk’ % (mount_dir)) and
                os.path.isfile(‘%s/boot/isolinux/boot2880.img’ % (mount_dir))):
            logging.info(‘        linux16′)
            fgb.write(
                ”’linux16 (loop)/boot/isolinux/memdisk
                initrd16 (loop)/boot/isolinux/boot2880.img\n”’)
        elif (os.path.isfile(‘%s/boot/vmlinuz’ % (mount_dir)) and
                os.path.isfile(‘%s/boot/core.gz’ % (mount_dir))):
            logging.info(‘        initrd’)
            append = parse_isolinux_config(mount_dir)
            fgb.write(
                ”’linux (loop)/boot/vmlinuz %s
                initrd (loop)/boot/core.gz\n”’ % (append))
        else:
            logging.info(‘        Unknow type, failed’)
        fgb.write(‘}\n’)
        os.system(‘umount %s’ % (mount_dir))


if __name__ == ‘__main__’:
    logging.basicConfig(level=’INFO’)
    logging.debug(‘Download dir: %s’ % (DOWNLOAD_DIR))
    firmwares = read_config(CONFIG_FILE)

    fgb = open_custom_grub_config()
    for name, url in firmwares:
        logging.info(‘Target: %s’ % (name))
        zp = download_firmware_zip(name, url)
        iso = extract_zip_to_iso(zp)
        move_iso_to_boot(iso)
        make_grub_menuentry(fgb, name, iso)
    fgb.write(‘}\n’)
    fgb.close()
    os.chmod(GRUB_FILE, 0o755)
    shutil.rmtree(DOWNLOAD_DIR)

    print(‘Generate GRUB rules in: %s’ % (GRUB_FILE))
    print(‘                ISO in: %s’ % (BOOT_ISO_DIR))
    print(‘Please run “update-grub2” or “grub-mkconfig -o /boot/grub/grub.cfg’)
    print(‘to generate new grub file.’)
    print(‘And reboot to choose “Crucial Firmware Update in GRUB2.\n’)
